Downloads

These free van build downloads from AVC RIG include templates, guides and 3D files to help you plan and finish your conversion.

Instructions, Information, and other free content to assist you in your build!

What's in Our Free Van Build Downloads

Planning tools include the Ford Transit 148 template, the 2026 Transit Order Guide and our own fuse map. The Ford Transit 148 template helps you visualize your build and plan efficiently. The order guide helps you get informed before you buy a Ford Transit.

Install helpers include the Espar install template, for correctly installing your Espar furnace under the passenger seat, and the ESPAR error reset guide.

For interior work, grab the L Track cutout template for proper measurements when cutting L Track into your AVC subfloor. Crew Van owners can use the Crew front window trim guide for proper wall kit integration at the driver front window column.

The unistrut dimensions guide helps you cut unistrut for cabinetry or other storage. The screw guide tool 3D file helps your wall panel screws look clean and professional.

Fun Extras and 3D Prints

The Velit 2000R AC controller holder is a 3D print, with print settings on Maker World. Fans of our logo can use the AVC RIG logo stencil. The AVC Kids road trip packet passes the time with coloring pages and puzzles.

Want to see the parts go in? Watch our install videos.
